Johnson 500 RPM 12V DC Geared Motor - Grade B

Name: Johnson 500 RPM 12V DC Geared Motor - Grade B
Brand: Thinking Robot
SKU: TR-MOTOR-JOHNSON-500-B
Price: 550 INR
Availability: InStock

SKU: TR-MOTOR-JOHNSON-500-B

₹550inclusive of all taxes

Only 10 left—order soon

Estimated delivery

Fri, 31 Jul

★

Shipping benefit

Free shipping ₹1,499+^*

*Standard delivery; eligible order value applies.

A robust 12V Johnson geared motor delivering approximately 500 RPM for fast robotic vehicles and mechanical projects. Its metal gearbox, 6mm side shaft and balanced torque-to-speed output make it suitable for roborace bots, automation systems and DIY machines.

Secure payments

Expert support

Easy replacements

Everything you need to know

Product details

Johnson 500 RPM 12V DC Geared Motor - Grade B

The Johnson 500 RPM geared motor combines a high-speed DC motor with a durable metal reduction gearbox. It is a practical choice for lightweight and medium-load robots where higher travel speed is required.

Key Features

500 RPM rated speed at 12V
Durable metal gearbox
Off-centred side shaft with metal bushes
6mm output shaft suitable for common robot wheels
Useful for fast robot cars, roborace platforms and automation mechanisms

Technical Specifications

Feature	Specification
Nominal Voltage	12V DC
Operating Voltage Range	6V to 18V DC
Rated Speed	500 RPM
Rated Torque	Approximately 1kg-cm
Stall Torque	Approximately 4.4kg-cm
No-Load Current	Approximately 300mA
Maximum Load Current	Approximately 900mA
Shaft Diameter	6mm
Shaft Length	Approximately 30mm
Gearbox Diameter	Approximately 37mm
Motor Diameter	Approximately 27mm
Motor Length	Approximately 62mm
Approximate Weight	162g
Gear Material	Metal

Driver Selection Note

Motor startup and stall current can be substantially higher than normal running current. Use a motor driver and power supply with adequate current headroom. Do not power this motor directly from a microcontroller pin.
