SmartElex 15D PWM & RC Dual-Channel Motor Driver - 15A

Name: SmartElex 15D PWM & RC Dual-Channel Motor Driver - 15A
Brand: Thinking Robot
SKU: TR-MD-SMARTELEX-15D
Price: 1400 INR
Availability: InStock

SKU: TR-MD-SMARTELEX-15D

₹1,400inclusive of all taxes

Only 2 left—order soon

Estimated delivery

Fri, 31 Jul

★

Shipping benefit

Free shipping ₹1,499+^*

*Standard delivery; eligible order value applies.

A versatile dual-channel SmartElex motor controller designed for high-performance robots, RC vehicles and automation projects. It supports RC, analog, PWM and serial control modes, with up to 15A continuous current per channel and built-in protection features.

Secure payments

Expert support

Easy replacements

Everything you need to know

Product details

SmartElex 15D PWM & RC Dual-Channel Motor Driver

The SmartElex 15D is a high-current dual-channel motor controller for independently controlling two brushed DC motors. Its multiple input modes make it useful for RC systems, microcontroller projects and standalone control applications.

Key Features

Controls two brushed DC motors independently
Supports RC, analog, PWM and serial control modes
Up to 15A continuous current per channel
Up to 30A peak current per channel
On-board push buttons for testing and manual control
Overcurrent and thermal protection
Automatic temperature-based output reduction
Suitable for high-performance robots and RC vehicles

Technical Specifications

Feature	Specification
Number of Motor Channels	2
Motor Supply Voltage	7V to 22V DC
Continuous Current	Up to 15A per channel
Peak Current	Up to 30A per channel
Control Modes	RC, Analog, PWM and Serial
Approximate PCB Size	105 × 74mm
Motor Type	Brushed DC motors

Installation Note

Use correctly rated cables, connectors, fuses and power sources. The driver current rating does not replace the need to check the motor's startup and stall-current requirements.
